External Shunt Module
Specifications
External shunt modules are used with Kinetix 6000 drives when
regenerative loads exceed the capacity of the internal (IAM or AM)
shunt resistor.
Passive shunt modules wire to the Kinetix 6000 (rail mounted) shunt
module, catalog number 2094-BSP2.
External Passive Shunt Module Specifications
Bulletin 1336 external active shunt modules wire directly to the dc
bus.
External Active Shunt Module Specifications
Refer to the Common DC Bus Selection Guide, publication
DRIVES-SG001, for dimensions and catalog number information for
the Bulletin 1336 active shunt modules.
External Shunt
Catalog Number
Drive
Voltage
V ac
Specifications
Bussmann
Replacement Fuse
Resistance
Ω
Peak
Power
kW
Peak
Current
A
Cont.
Power
W
Shipping
Weight
kg (lb)
1394-SR9A
230
(1)
4
41.0 101.25
300 3.63 (8)
FNQ-R-20-R1
(1)
460 160.0 20.0 FWP50A14F
1394-SR9AF
230
(1)
4
41.0 101.25
900 3.63 (8)
FNQ-R-20-R1
(1)
460 160.0 20.0 FWP50A14F
1394-SR36A
230
(1)
4
41.0 101.25
1800 8.6 (19)
FNQ-R-20-R1
(1)
460 160.0 20.0 FWP50A14F
1394-SR36AF
230
(1)
4
41.0 101.25
3600 9.0 (20)
FNQ-R-25-R1
(1)
460 160.0 20.0 FWP50A14F
(1)
Requires the use of an FNQ fuse with an adapter to allow the smaller body fuse to fit the larger FWP fuse holder.
Kinetix 6000 Drives
Shunt Module
Catalog Number
Specifications
Fuse Replacement
Drive
Voltage
V ac
Resistance
Ω
Peak
Power
kW
Peak
Current
A
Continuous
Power
W
Shipping
Weight
kg (lb)
2094-ACxx-Mxx
1336-MOD-KA005
230V
28.0 6 15 375
6.8 (15)
A50P10
1336-MOD-KA010 13.2 12 30 750 A50P20
2094-BCxx-Mxx
1336-MOD-KB005
460V
104.0 6 7.5 375 A60Q
1336-MOD-KB010 52.0 12 15 750 A60Q
1336-MOD-KB050 10.0 60 76 3750 33.8 (75) A70QS35
