16 Start
Catalog Number
Explanation
Kinetix 6000 drive catalog numbers and descriptions are listed in the
table below.
Kinetix 6000 Drive Catalog Numbers
Agency Compliance
If this product is installed within the European Union or EEC regions
and has the CE mark, the following regulations apply.
Integrated Axis Modules (230V
Catalog Number
(with safe-off feature)
Catalog Number
(without safe-off feature)
Kinetix 6000, IAM, 230V, 3 kW converter, 5 A inverter 2094-AC05-MP5-S 2094-AC05-MP5
Kinetix 6000, IAM, 230V, 3 kW converter, 9 A inverter 2094-AC05-M01-S 2094-AC05-M01
Kinetix 6000, IAM, 230V, 6 kW converter, 15 A inverter 2094-AC09-M02-S 2094-AC09-M02
Kinetix 6000, IAM, 230V, 11 kW converter, 24 A inverter 2094-AC16-M03-S 2094-AC16-M03
Kinetix 6000, IAM, 230V, 23 kW converter, 49 A inverter 2094-AC32-M05-S 2094-AC32-M05
Integrated Axis Modules (460V)
Kinetix 6000, IAM, 460V, 6 kW converter, 4 A inverter 2094-BC01-MP5-S 2094-BC01-MP5
Kinetix 6000, IAM, 460V, 6 kW converter, 9 A inverter 2094-BC01-M01-S 2094-BC01-M01
Kinetix 6000, IAM, 460V, 15 kW converter, 15 A inverter 2094-BC02-M02-S 2094-BC02-M02
Kinetix 6000, IAM, 460V, 28 kW converter, 30 A inverter 2094-BC04-M03-S 2094-BC04-M03
Kinetix 6000, IAM, 460V, 45 kW converter, 49 A inverter 2094-BC07-M05-S 2094-BC07-M05
Axis Modules (230V)
Kinetix 6000, AM, 230V, 5 A 2094-AMP5-S 2094-AMP5
Kinetix 6000, AM, 230V, 9 A 2094-AM01-S 2094-AM01
Kinetix 6000, AM, 230V, 15 A 2094-AM02-S 2094-AM02
Kinetix 6000, AM, 230V, 24 A 2094-AM03-S 2094-AM03
Kinetix 6000, AM, 230V, 49 A 2094-AM05-S 2094-AM05
Axis Modules (460V)
Kinetix 6000, AM, 460V, 4 A 2094-BMP5-S 2094-BMP5
Kinetix 6000, AM, 460V, 9 A 2094-BM01-S 2094-BM01
Kinetix 6000, AM, 460V, 15 A 2094-BM02-S 2094-BM02
Kinetix 6000, AM, 460V, 30 A 2094-BM03-S 2094-BM03
Kinetix 6000, AM, 460V, 49 A 2094-BM05-S 2094-BM05
Shunt Module
Kinetix 6000, SM, 230V/460V, 200W N/A 2094-BSP2
ATTENTION
Meeting CE requires a grounded system, and the method of
grounding the ac line filter and drive must match. Failure to do
this renders the filter ineffective and may cause damage to the
filter.
For grounding examples, refer to Grounded Power
Configurations on page 71.
