Rockwell Automation Allen-Bradley Kinetix 6000 User Manual

Publication 2094-UM001A-EN-P — September 2006
Connecting the Kinetix 6000 Drive System 87
Wiring the Control Power Output (CPL) Connector
Line Interface Module (CPL connector)
Control Power Output (CPL) Connector
2094-ALxxS, -BLxxS, -XL75S-Cx
Control Power Output (CPL) Connector
2094-AL09 and -BL02
CTRL 2
CTRL 1
1 2
Line Interface Module, Top View
(2094-XL75S-Cx is shown)
CPL Pin Signal
Recommended
Wire Size
mm
2
(AWG)
Strip Length
mm (in.)
Torque Value
Nm (lb-in)
1CTRL 1
0.2-4.0
(24-10)
7.0
(0.28)
0.5 - 0.6
(4.4 - 5.3)
2CTRL 2
CPL Pin Signal
Recommended
Wire Size
mm
2
(AWG)
Strip Length
mm (in.)
Torque Value
Nm (lb-in)
2L1
2.5
(14)
10.0
(0.38)
0.5 - 0.6
(4.4 - 5.3)
1L2/N
