Chapter
3
Mounting the Kinetix 6000 Drive System
Introduction
This chapter provides the system installation procedures for mounting
your Kinetix 6000 drive components to the panel.
The procedures in this chapter assume you have prepared your panel
and understand how to bond your system. For installation instructions
regarding equipment and accessories not included here, refer to the
instructions that came with those products.
Using 2094 Mounting Brackets
Bulletin 2094 mounting brackets can be used to mount the power rail
or line interface module over the ac line filter. Refer to the 2094
Mounting Brackets Installation Instructions, publication 2094-IN008,
when using mounting brackets with your Kinetix 6000 drive system.
Topic Page
Introduction 43
Determining Mounting Order 44
Mounting the Modules 45
Mounting the External Shunt Module 48
SHOCK HAZARD
To avoid hazard of electrical shock, perform all mounting and
wiring of IAM, AM, SM, LIM, RBM, or power rail prior to
applying power. Once power is applied, connector terminals
may have voltage present even when not in use.
ATTENTION
Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed
from the enclosure. Because the system is of the open type
construction, be careful to keep any metal debris from falling
into it. Metal debris or other foreign matter can become lodged
in the circuitry, which can result in damage to components.
