DC Common Bus Applications 233
Kinetix 6000 Capacitance
Values
Use the tables below when calculating total bus capacitance and
additional bus capacitance for your Kinetix 6000 common bus
application.
IAM/AM (230V) Modules
IAM/AM (460V) Modules
SM (230/460V) Module
IAM Converter (230V)
Capacitance
µF
AM Inverter (230V)
Capacitance
µF
2094-AC05-MP5-S
270
2094-AMP5-S 390
2094-AC05-M01-S 2094-AM01-S 660
2094-AC09-M02-S 540 2094-AM02-S 780
2094-AC16-M03-S 1320 2094-AM03-S 1320
2094-AC32-M05-S 1980 2094-AM05-S 2640
IAM Converter (460V)
Capacitance
µF
AM Inverter (460V)
Capacitance
µF
2094-BC01-MP5-S
110
2094-BMP5-S 75
2094-BC01-M01-S 2094-BM01-S 150
2094-BC02-M02-S 220 2094-BM02-S 270
2094-BC04-M03-S 940 2094-BM03-S 840
2094-BC07-M05-S 1410 2094-BM05-S 1175
SM (230-460V)
Capacitance
μF
2094-BSP2 470
