182 Specifications and Dimensions
Weight Specifications
Certifications
Kinetix 6000
Module
Catalog Number
Value, Approx.
Kinetix 6000
Module
Catalog Number
Value, Approx.
kg (lb) kg (lb)
IAM
(230V)
2094-AC05-MP5-S 2.23 (4.9)
IAM
(460V)
2094-BC01-MP5-S 4.98 (11.0)
2094-AC05-M01-S 2.27 (5.0) 2094-BC01-M01-S 5.03 (11.1)
2094-AC09-M02-S 2.31 (5.1) 2094-BC02-M02-S 5.08 (11.2)
2094-AC16-M03-S 4.71 (10.4) 2094-BC04-M03-S 9.60 (21.1)
2094-AC32-M05-S 7.43 (16.4) 2094-BC07-M05-S 10.1 (22.3)
AM
(230V)
2094-AMP5-S 1.46 (3.2)
AM
(460V)
2094-BMP5-S 2.44 (5.4)
2094-AM01-S 1.50 (3.3) 2094-BM01-S 2.49 (5.5)
2094-AM02-S 1.54 (3.4) 2094-BM02-S 2.54 (5.6)
2094-AM03-S 3.13 (6.9) 2094-BM03-S 4.58 (10.1)
2094-AM05-S 3.18 (7.0) 2094-BM05-S 4.98 (11.0)
Power Rails
(Slim)
2094-PRS1 1.05 (2.3)
Power Rails
2094-PR1 1.04 (2.3)
2094-PRS2 1.59 (3.5) 2094-PR2 1.41 (3.1)
2094-PRS3 2.14 (4.7) 2094-PR4 2.18 (4.8)
2094-PRS4 2.67 (5.9) 2094-PR6 2.90 (6.4)
2094-PRS5 3.11 (6.8) 2094-PR8 3.63 (8.0)
2094-PRS6 3.55 (7.8)
2094-PRS7 3.99 (8.8) SM (460V) 2094-BSP2 3.10 (6.8)
2094-PRS8 4.43 (9.7) Slot Filler Module 2094-PRF 0.45 (1.0)
Certification
(1)
(when product is marked)
Standards
c-UL-us UL Listed to U.S. and Canadian safety standards (UL 508 C File E59272).
CE
European Union 89/336/EEC EMC Directive compliant with EN 61800-3:2004:
Adjustable Speed Electrical Power Drive Systems - Part 3; EMC Product
Standard including specific test methods.
European Union 73/23/EEC Low Voltage Directive compliant with:
• EN 60204-1:1997 - Safety of Machinery - Electrical Equipment of Machines.
• EN 50178:1997 - Electronic Equipment for use in Power Installations.
Functional Safety
• EN 60204-1:1997 - Safety of Machinery - Electrical Equipment of Machines.
• IEC 61508: Part 1-7:2000 - Functional Safety of Electrical/Electronic/
Programmable Electronic Safety-related Systems.
• EN954-1:1996 - Safety of machinery. Safety related parts of control systems.
Part 1: General principles for design.
(1)
Refer to http://www.rockwellautomation.com/products/certification for Declarations of Conformity Certificates.
