180 Specifications and Dimensions
Power Dissipation
Specifications
Use the following table to size an enclosure and calculate required
ventilation for your Kinetix 6000 drive system.
Kinetix 6000 Modules
Usage as % of Rated Power Output
(watts)
20% 40% 60% 80% 100%
Integrated axis module (IAM converter)
(1)
2094-AC05-MP5-S
19 23 27 31 35
2094-AC05-M01-S
2094-AC09-M02-S 33 51 69 87 105
2094-AC16-M03-S 18 38 60 83 108
2094-AC32-M05-S 31 64 102 144 190
2094-BC01-MP5-S
15 20 25 30 35
2094-BC01-M01-S
2094-BC02-M02-S 20 30 40 50 60
2094-BC04-M03-S 22 43 65 86 108
2094-BC07-M05-S 44 77 111 144 177
Integrated axis module (IAM Inverter) or axis module (AM)
(1)
2094-AC05-MP5-S or -AMP5-S 60 65 70 75 80
2094-AC05-M01-S or -AM01-S 62 69 76 83 90
2094-AC09-M02-S or -AM02-S 64 73 82 91 100
2094-AC16-M03-S or -AM03-S 50 72 99 130 165
2094-AC32-M05-S or -AM05-S 106 160 220 285 356
2094-BC01-MP5-S or -BMP5-S 75.7 80.9 86 92 98
2094-BC01-M01-S or -BM01-S 95 120 145 170 195
2094-BC02-M02-S or -BM02-S 98 126 154 182 210
2094-BC04-M03-S or -BM03-S 95 132 171 212 256
2094-BC07-M05-S or -BM05-S 118 182 251 326 406
Shunt module (SM)
2094-BSP2 68 121 174 227 280
(1)
Internal shunt power is not included in the calculations and must be added based on utilization.
