Service Manual SC 7000 and SC 9000XL Patient Monitors
90 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.c5.CD_ROM.fm/04-99/kaupp
16Patient-Related Data Not Retained or Monitor Fails to Compute Trends
Replace Main PCB Subassembly. If problem persists, contact TSS in Solna
or in Danvers.
17Software Loading Problems
For problems concerning software downloads, refer to software installation
instructions for version of software you are attempting to install.
18Difficulty acquiring export protocol data
This problem is usually caused by an incorrect connection or
communications protocol. Refer to I
NFINITY
RS-232 Export Protocol
Reference Booklet, Art. No. 64 93 212 E315U.
19Total or partial loss of network communications
Temporary network communication losses are caused by either an inter-
ruption between the monitor and the IDS/CPS, with the Ethernet port on the
main processor, or in the network line.
1)• For non-DirectNet installations, connect another monitor to suspect
IDS/CPS to determine if problem is related to monitor or to IDS/CPS.
• For DirectNet network connection, verify that network configuration
data in monitor are correct. See Section 3, “Configuration
Parameters”, and Section 4, “Configuring Monitor”, in Appendix E.
2) Replace Main Processor PCB Subassembly if problem isolated to
monitor.
Local Recorder
connected to Monitor
through CPS or IDS
Recorder malfunction
CPS/IDS - Recorder
cable malfunction
Recorder Interface Plate
malfunction
CPS or IDS malfunction
Docking Station or CPS
Bridge Plate malfunction
Monitor malfunction
1. With an ECG waveform on Monitor display, provided
by patient simulator, press Record key.
2. • If “Recorder Not Connected” message appears,
check cables and connections between Monitor,
CPS/IDS, and Recorder. If problem persists,
continue to step 3.
• Press Zoom key and select Event Recall. After ≈20
sec, BED TIMED strip should appear. If BED
TIMED strip fails to appear, replace Front Bezel
Subassembly and go to step 5.
3. Substitute Recorder cable Art. No. 43 18 130 E530U
in place of Docking Station, CPS/IDS, and cabling.
4. • If problem persists, replace Recorder.
• If problem disappears, replace each component
substituted in step 3 to isolate source of problem
and replace malfunctioning component.
5. If problem persists, replace Main Processor PCB
Subassembly.
6. If problem persists, contact TSS in Solna or Danvers.
Table 5-12 Recorder Problems (Continued)
Symptoms Possible Cause(s) Troubleshooting and Remedial Action
To Next Page
