Service Manual SC 7000 and SC 9000XL Patient Monitors
58 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.c4.CD_ROM.fm/04-99/kaupp
Table 4-1Recommended Tools and Test Equipment
Tools & Test Equipment Description
ECG/Resp:
Patient ECG/Resp simulator DNI Medsim 300B or equivalent
Leads: Three-lead grabber set, or IEC color code 1
IEC color code 2
Art. No. 33 75 230 E530U
Art. No. 33 75 248 E530U
Five-lead grabber set IEC color code 1
IEC color code 2
Art. No. 33 75 255 E530U
Art. No. 33 75 263 E530U
SpO
2
Patient SpO
2
simulator, or Nellcor PT2500 or equivalent
Reusable SpO
2
sensor: Durasensor Adult Art. No. 45 34 475 EH50U
Non-Invasive Blood Pressure:
*NBP simulator (calibrated) or Dynatech CuffLink, or Veri-Cal
Pressure Transducer Tester, or
equivalent
*Mercury manometer with hand bulb Baumanometer, 0-300 mmHg
NBP Calibration Assembly Art. No. 28 77 855 EE54U
NBP connection hose, 3.7 m Art. No. 12 75 275 EH40U
etCO
2
5.00 ±0.03% CO
2
, balance N
2
, Calibration Gas Cylinder Art. No. 28 68 532 EE54U
Calibration Gas Regulator, with elbow fitting Art. No. 28 68 540 EE54U
Mercury barometer with mm grade
Invasive blood pressure:
IBP simulator w/ test cable DNI Medsim 300B or equivalent
Cardiac Output
SHP ACC C.O. INTERMEDIATE CABEL Art. No. 33 68 458 E530U
Temperature
Temperature simulator w/ test cable (2 cables req’d) DNI Medsim 300B or equivalent
Temperature Y Cable Art. No. 55 92 154 E530U
SHP ACC TEMP ADPT CBL 1/4” JACK (2 req’d) Art. No. 51 98 333 E530U
Leakage
Leakage Tester Bender µP-Safety Tester 601/751,
or equivalent
Output Cables:
Recorder ÷ Interface Plate or CPS/IDS Art. No. 47 21 770 E530U
IDS (or equivalent CPS), unless Monitor used only in DirectNet mode Art. No. 52 60 110 E5460
*For functional verification and calibration check. For calibration, Paroscientific Pressure Meter, Model 740-
12D, or equivalent, is recommended. An equivalent must be accurate to ±0.3 mmHg from 0 to 330 mmHg.
