ASK-T898-03-7600 Siemens Medical Systems, EM-PCS Danvers 37
7k9kXLSM.c3.CD_ROM.fm/04-99/kaupp NOT A CONTROLLED DOCUMENT
Chapter 3: Repair
1Introduction
This chapter describes how to disassemble SC 7000 and SC 9000XL
Patient Monitors, replace parts and subassemblies that Siemens has
identified as field-replaceable (see “Appendix A: Replacement Parts” ), and
reassemble the monitors. The structure of an SC7000 or an SC 9000XL
consists of a base unit with attachable modules and pods.
Warning
After replacing a part or subassembly, always functionally verify
proper operation of the monitor, before returning the monitor to
clinical service.
2 Service Policy and
Replaceable Parts
Qualified service personnel may replace the following specific items in the
field. Except for specified items, component-level repairs should not be
attempted and will void any warranty or exchange allowance for returned
subassemblies. A complete list of replaceable components and part
numbers is given in Appendix A.
2.1 Base Unit
Front Bezel/Lens Subassembly
Language Label Set
LCD Backlight Lamps
Optical Encoder Subassembly
Rotary Knob
Front Bezel PC Board
Front Bezel Subassembly w/ Language Label Set
NP Pump Subassembly
NP Filters
Batteries (main and external)
Power Harness w/ Speaker
External Battery Compartment Door and Ejection Spring
Main Processor PCB Subassembly
Funnel
Monitor Handle
Rear Housing Side Panels w/ Label Set
Rear Housing / Connector I/O PCB
F1, F2, and F3 on Connector I/O PCB
2.2 R50 Recorder
Since an R50 Recorder operates in conjunction with the monitors,
replaceable subassemblies for the R50 are included in Appendix A.
Front bezel
Printer subassembly
A100 PC Board
