Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
98 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apa.CD_ROM.fm/04-99/kaupp
Figure A-5Security Clip H/W Rwk Kit (See Table A-5.)
Figure A-6 NBP Filter Capacitor on Main PCB H/W Rwk Kit (See Table A-5.)
61
62
Table A-5 Field Rework Kits
Item No. Description
Siemens Article
Number
61 H/W RWK KIT BEZEL LOCK 59 50 535 E539U
62 H/W RWK KIT NBP ESU 59 49 677 E539U
