Siemens SC 7000 Service Manual

SC 7000 and SC 9000XL Patient Monitors Service Manual
ASK-T898-03-7600 Siemens Medical Systems, EM-PCS Danvers 63
7k9kXLSM.c4.CD_ROM.fm/04-99/kaupp
NOT A CONTROLLED DOCUMENT
• HR in parameter field = 120
• HR parameter field blinks and color changes.
• Serious Alarm tone sounds.
• Message HR > 110 appears in message area at bottom of display.
4) Reset simulator to HR = 80 bpm.
5) Verify the following:
• HR parameter field returns to normal color
• HR returns to 80
• Message area continues to report most recent alarm, HR >110.
6) Press Alarm Silence fixed key.
7) Verify that “HR > 110” ceases to be reported.
7.6 Asystole
Switch power to simulator OFF. Verify that HR parameter field reports ASY,
“Asystole” appears in message area at bottom of display, and monitor
responds with Life-Threatening alarm.
Switch power to simulator ON.
8SpO
2
Function
The SC 7000 and SC 9000XL monitor oxygen saturation (SpO
2
) and pulse
rate using the spectrophotometric method. SpO
2
software is checked on
monitor power-up and also periodically while the monitor is in operation.
8.1 SpO
2
Test Setup
The SpO
2
parameter box appears when an SpO
2
input is applied to the
monitor through the MultiMed POD.
1) Select SpO
2
parameter box to access menu. Set parameters as follows:
• Pulse Tone Source - SpO
2
• Pulse Tone Volume -10%
• Waveform Size - 10%
• Averaging - Normal
2) Do either of the following as appropriate:
a If using a variable SpO
2
simulator, set SpO
2
level to 98% and
pulse rate to 70 bpm, and plug simulator into SpO
2
input adapter
cable to MultiMed POD.
b If using a Nellcor PT-2500 pocket tester or equivalent, plug tester
into SpO
2
input adapter cable to MultiMed POD.
8.2 Waveforms/Digital
Readouts/Tones
1) Verify the following:
• Simulated SpO
2
waveform appears, and digital SpO
2
and pulse rate
(PLS) values correspond to simulator settings.
•
♥
symbol blinks in SpO
2
field, and pulse tone sounds synchronous
with appearance of
♥
symbol.
8.3 Pulse Tone Generator
1) Select Pulse Tone Volume in SpO
2
menu.
2) Vary volume setting and verify that pulse tone volume changes.
3) Set Pulse Tone Volume to OFF, and verify that tone stops. Then reset
pulse tone to ON.
