Siemens SC 7000 Service Manual

Service Manual SC 7000 and SC 9000XL Patient Monitors
104 Siemens Medical Systems, EM-PCS, Danvers ASK-T898-03-7600
NOT A CONTROLLED DOCUMENT
7k9kXLSM.apb.CD_ROM.fm/04-99/kaupp
7 MultiMed Pod Cable Connector
on SC 7000 / SC 9000XL
Figure B-10MultiMed Pod Cable Connector
Table B-8 MultiMed Pod Cable Connector Pinouts
MultiMed Pod Cable Connector
Pin No. Signal
1 RCALIB
2REDK
3 HVPODIDR
4VEE_1
5 LFT_LEG
6DET_A
7DET_K
8TB
9TCOM
10 RT_LEG
11 LFT_ARM
12 (RCALRTN)
13 IRK
14 TA
15 VEE_2
16 RT_ARM
















8 HemoMed Pod Cable Connector
on SC 7000 / SC 9000XL
Figure B-11HemoMed Pod Cable Connector
Table B-9 HemoMed Pod Cable Connector Pinouts
HemoMed Pod Cable Connector
Pin No. Signal
1-IBP1
2-IBP2
3-IBP3
4-IBP4
5 P1SWITCHES
6 +IBP1
7 +IBP2
8 +IBP3
9 +IBP4
10 TINJ
11 CO_SW_RET
12 PRES_RET
13 PRES1_3+
14 PRES2_4+
15 7R37
16 TBLD
















