13.1.3 HEMO2/4 POD Channel B 12) Unplug BP adapter cable from channel A on HEMO POD and plug it
into channel B.
13) Observe that pressure label changes to same pressure label as is
shown in LCD window for channel B on front of HEMO POD.
14) Verify that pressure reading on monitor is in agreement with values
generated by pressure signal from simulator.
15) Do either step a or step b as appropriate.
a If the HEMO POD has four channels, unplug the BP adapter cable
from channel B and plug it into channel C. then go on to step 16.
b If the HEMO POD has only two channels, bypass remaining steps
of this section and go to section 13.2.
13.1.4 HEMO4 POD Channel C 16) Unplug BP adapter cable from channel B on HEMO POD and plug it
into channel C.
17) Observe that pressure label changes to same pressure label as is
shown in LCD window for channel C on front of HEMO POD.
18) Verify that pressure reading on monitor is in agreement with values
generated by pressure signal from simulator.
13.1.5 HEMO4 POD Channel D 19) Unplug BP adapter cable from channel C on HEMO POD and plug it
into channel D.
20) Observe that pressure label changes to same pressure label as is
shown in LCD window for channel D on front of HEMO POD.
21) Verify that pressure reading on monitor is in agreement with values
generated by pressure signal from simulator.
22) Unplug simulator input adapter cable from HEMO POD, and go on to
section 13.2.
13.2 Temperature Function
1) Plug fixed temperature (37°C) output from simulator into TEMP A
connector HEMO POD.
2) Plug selectable temperature output from simulator into TEMP B
connector HEMO POD, and set temperature for other than 37°C.
3) Verify the following:
• T field appears on
MAIN
screen
• T1a temperature = 37 ±0.1°C
• T1b temperature = simulator setting ±0.1°C.
4) Select Temperature field, and access TEMP1 menu.
5) Select TEMP Display and then select .
6) Verify that T1b changes to and reports temperature difference
between T1a and T1b ±0.2°C.
7) Reset TEMP Display in TEMP1 menu to T1b.
8) Press Main Screen key to clear table and return to
MAIN
Screen.
13.3 Cardiac Output
Function
1) Plug C.O. output from simulator into C.O. test adapter cable, and plug
adapter cable into C.O./Temp B input on HEMO POD.
2) When READY appears in CO parameter field verify that blood
temperature indication is 37±0.15°C.
∆T1
∆T1
To Next Page
