Siemens SIPROCESS GA700 Operating Instructions

8.2.4 Connecting signal cables
We recommend the following cable cross-sections for use as signal cables:
• Solid conductor 0.08 … 2.5mm² / 28 … 12AWG
• Finely-stranded conductor 0.08 … 2.5mm² / 28 … 12AWG
• Finely-stranded conductor; with end sleeve with plastic collar 0.25 … 1.5 mm² / 23 … 16 AWG
• Finely-stranded conductor; with end sleeve without plastic collar 0.25 … 2.5 mm² / 23 … 12
AWG
Note
The stripped length should be 5 … 6mm / 0.2 … 0.24".
Connecting the device
8.2Electrical connections
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 107
