Siemens SIPROCESS GA700 Operating Instructions

4.4 OXYMAT 7
4.4.1 Module structure, standard version






① Reference gas inlet ⑤ Power supply connection
② Not assigned ⑥ Connection for optional module 2.x
(OM2.x)
③ Sample gas outlet ⑦ Connection for internal bus communication
(CAN)
④ Sample gas inlet  
Figure4-4 Design OXYMAT7, high-pressure version, measurement gas path with pipes
Description
4.4OXYMAT 7
Wall-mounted device
26 Operating Instructions, 07/2023, A5E31930403-AB
