7.10 Removing ULTRAMAT 7, high-temperature version
Overview
]
Z
\
X
Y
[
① Wall-mounted device ④ Analyzer module ULTRAMAT 7, high-temperature
version with module insulation
② Screw for door (6 units) ⑤ Flat seal
③ Torx screw for housing 󹪞oor (8 units) ⑥ Equipotential bonding cable
Figure7-11 Removing ULTRAMAT 7 high-temperature
Installing / removing and connecting analyzer and option modules
7.10Removing ULTRAMAT 7, high-temperature version
Wall-mounted device
80 Operating Instructions, 07/2023, A5E31930403-AB
