A.5.2 Spare parts wall-mounted device
Table A-9 Spare parts list wall-mounted device - standard version
Article number Name Description Classi󹪝ca‐
tion
A5E03859944 Blank plate analyzer modules Blank plate with fastening screws and equipotential bonding,
seal and instructions
1
A5E03859961 Blank plate gas management Blank plate with fastening screws and equipotential bonding,
seal and instructions
1
A5E03859986 Sealing set Seal: 2xmodules, GM, terminal connection and door seal 1
A5E03859990 Door seal Door seal 1
A5E03860003 Cable gland seal For unused cable glands 1
A5E03860009 Keyboard Keyboard with polycarbonate pane and spacer with 󹪞at seal
and packaging
2
A5E03860010 Seal display Flat seal between door and display module 2
A5E03860011 Cable gland set For all 8 openings 1
A5E03860017 Door, complete Door including seal, hinge, protective conductor, packaging 2
A5E03860020 Purging gas stubs Purging gas stubs, tube, seal, tube clamp 1
A5E03860127 Processing unit Processing unit with 󹪝xing screws, packaging 1
A5E03860130 Option module 2.2 Option module with 󹪝xing screws, packaging 1
A5E03860137 Option module 1.1 (addition‐
al DI/DQ)
Option module with 󹪝xing screws, packaging 1
A5E03860138 Option module 2.1 (6xAO,
6DQ)
Option module with 󹪝xing screws, packaging 1
A5E03860142 LUI FBG LUI FBG (no expanding rivet, because provided by service
technician), packaging
1
A5E03860162 Standard terminal block Standard terminal block with screws 1
A5E03860165 Terminal block options Terminal block options with screws 1
A5E03860170 Display LCD display 1
A5E03862674 Power supply unit Power supply unit with screws and ground cable 1
A5E03860180 Power connector Appliance plug 1
A5E03860189 Connecting cables TB-PU Connecting cable terminal block to processing unit 1
A5E03860938 CAN cable CAN bus cable 1
A5E03860941 Supply cable PU Supply cable for processing unit 1
A5E03860948 Supply cable GM / AM Supply cable for analyzer module (wall-mounted device) 1
A5E03860962 Connecting cable PU - LUI Connecting cable for processing unit - front panel 1
A5E03860966 Connecting cable AM - OM 2.x Connecting cable for analyzer module 1 - optional module 2.x 1
A5E03860971 Connecting cable TB - OM 2.1 Connecting cable for standard terminal block option module
2.1
1
A5E03860981 Connecting cable TB - OM2.2 Connecting cable for standard terminal block option module
2.2
1
A5E03860984 Connecting cable TB - OM 1.x Connecting cable for standard terminal block option module 1 1
A5E03860986 Connecting cable TB - TB Connecting cable standard terminal block to option 1 terminal
block
1
A5E03860997 Data cable PU - OM1 Data cable for processing unit - option module 1 1
Appendix
A.5Spare parts/accessories
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 183
