5.4.6 Operation with di󹪜erent analyzer modules
OXYMAT7/ ULTRAMAT7/ CALOMAT 7
Table 5-4 Mounting conditions and positions for the sample gas restrictor
Operating
mode
Sample gas restrictor/clamping screw
OXYMAT7/ ULTRAMAT7

ULTRAMAT7/ CALOMAT 7 OXYMAT7/ CALOMAT7
Pressure op‐
eration
OXYMAT7 must always be
󹪞owed 󹪝rst.
Install a sample gas restric‐
tor in front of the sample
gas inlet of the OXYMAT7.
We recommend 󹪞owing the
CALOMAT7 as the 󹪝rst mod‐
ule

No restrictions
Suction oper‐
ation
ULTRAMAT7 must always
be 󹪞owed 󹪝rst.
Install a sample gas restric‐
tor in the sample gas outlet
of the OXYMAT7.
Replace a sample gas re‐
strictor in the sample gas
inlet of the OXYMAT 7 with
a clamping screw.
Combined operation
5.4Application planning
Wall-mounted device
50 Operating Instructions, 07/2023, A5E31930403-AB
