Siemens SIPROCESS GA700 Operating Instructions

Article number Name Description Classi󹪝ca‐
tion
A5E03790515 Set of self-locking screws  1
A5E43896751 Module packaging C7-O7-U7 1
A5E43897960 Module packaging O7, for analyzer modules in high-temperature version 1
A5E03878052 Set of cables  1
A5E03790507 Analyzer module FBG For analyzer modules in standard version 1
A5E35686750 Retaining plate with small
parts set
For mounting the FBG A5E03790512 or the pressure sensor
A5E03790214 / A5E03790215
1
A5E35681466 Union nut for customer con‐
nection (set)
Swagelok nut clamping ring set for 6 mm pipe, stainless steel 1
A5E35687155 Union nut for customer con‐
nection (set)
Swagelok nut clamping ring set for 6 mm pipe, Hastelloy 1
A5E35681883 Set of 4A fuses AM-FBG, set of 6x 4A fuses 1
A5E46488062 Ferrite measuring head cable
HT
For analyzer modules in high-temperature version, for instal‐
lation of measuring head cable to the analyzer module
1
A5E45566579 FBG HT heating cartridge con‐
trol
For analyzer modules in high-temperature version, printed
circuit board heating cartridge control with spacing bolts and
screws
1
A.5.4 Spare parts ULTRAMAT 7
Table A-12 Spare parts list ULTRAMAT 7 - IR source, standard and high-temperature version
Article number Name Description Classi󹪝ca‐
tion
A5E35255648 IR source For standard module, 2 gas connections, stainless steel, non-
󹪞ow type, sealed
*
A5E41793434 IR source For standard module, 2 gas connections, stainless steel,
cleaned for O
2
, non-󹪞ow type, sealed
*
A5E41004050 IR source For standard module, 2 gas connections, Hastelloy, non-󹪞ow
type, sealed
*
A5E41793555 IR source For standard module, 2 gas connections, Hastelloy, cleaned
for O
2
, non-󹪞ow type, sealed
*
A5E35255650 IR source For standard module, 4 gas connections, stainless steel, 󹪞ow-
type, sealed
*
A5E41795139 IR source For standard module, 4 gas connections, stainless steel,
cleaned for O
2
, 󹪞ow-type, sealed
*
A5E41004110 IR source For standard module, 4 gas connections, Hastelloy, 󹪞ow-type,
sealed
*
A5E41799637 IR source For standard module, 4 gas connections, Hastelloy, cleaned
for O
2
, 󹪞ow-type, sealed
*
A5E35255669 IR source For standard module, without 2 gas connections, non-󹪞ow
type, sealed
*
A5E35255673 IR source For standard module, without 4 gas connections, 󹪞ow-type,
sealed
*
Appendix
A.5Spare parts/accessories
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 187
