Siemens SIPROCESS GA700 Operating Instructions

8.1.4.2 ULTRAMAT 7
ULTRAMAT 7: Arrangement of the gas connections in the wall-mounted device
3




1234
① Purging gas inlet
② Purging gas outlet
③ Slot of analyzer module 2
④ Slot of analyzer module 1: ULTRAMAT 7
 1 Sample gas inlet
 2 Sample gas outlet
 3 Reference gas outlet
 4 Reference gas inlet
 P Atmospheric pressure sensor
Figure8-3 ULTRAMAT 7 gas connections in the wall mounted device, lower side
Connecting the device
8.1Gas connections
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 97
