7.12 Wiring option modules
Overview
① Analyzer module printed circuit board
② Interface
Figure7-17 Connecting option modules based on the example of an OXYMAT 7
Note
ULTRAMAT 7: Deviating position of the OM2.x connections
With ULTRAMAT 7 analyzer modules the connector of the option module is not on the printed
circuit board but is on an additional circuit board. This is mounted horizontally at the upper end
of the analyzer module (see image of the ULTRAMAT 7 in paragraph Module structure, standard
version (Page32)).
Installing / removing and connecting analyzer and option modules
7.12Wiring option modules
Wall-mounted device
88 Operating Instructions, 07/2023, A5E31930403-AB
