5.5.2 Notes on conguration change
NOTICE
Damage caused by inadmissible procedure/faulty operations
Inadmissible procedure and/or faulty operations can result in damage to the device or its
modules/electronic equipment in connection with Plug & Measure. Therefore:
• Observe the specications regarding installation/removal of the device hardware.
• Carefully read the following information on dierent Plug & Measure cases.
NOTICE
Deletion of the analyzer module parameter assignment due to faulty operation during
commissioning
During commissioning after replacement of the AM electronics, a faulty operation can prevent
transfer of the parameters and render the AM electronics unusable. When you commission the
device once again after replacing the AM electronics, the following applies:
• First, conrm the message regarding the change of the conguration.
• Make sure to conrm the transfer of the parameters by pressing <ENTER>.
• Always carry out a normalization. To do this calibrate the analyzer module in the service
menu as follows:
"Main menu" > "2. Settings" > "20. Service" > "03. Factory calibrations" > "03. Normalization".
Note
Authorization level
To execute the actions described below, you must be logged on with at least the "Expert"
authorization level. You may have to log on again with the requested PIN.
Message panel for conguration change
When you change the hardware equipment of the device by replacing or adding modules or
components, the LUI alarm window "Device congurationchanged" is displayed during re-
commissioning.
To start the data synchronization, conrm the alarm by pressing <ENTER>.
Depending on the concrete application adapt the required parameter sets in the message
panel "Transfer parameters". Information on the further procedure is available in the tables
below.
Combined operation
5.5Plug & measure permitted activities
Wall-mounted device
54 Operating Instructions, 07/2023, A5E31930403-AB
