Siemens SIPROCESS GA700 Operating Instructions

13.3.3 CALOMAT 7 technical speci󹪝cations
Table 13-28 CALOMAT 7: General technical speci󹪝cations
General
Information on the smallest span See module nameplate
Power consumption < 20W
Weight Approx. 3kg
Electrical safety In accordance with DINEN61010-1
Max. EMC error during operation of one and/or
two CALOMAT 7 units
2.0% according to EN 61326-1 (2013)
Table 13-29 CALOMAT 7: Measuring ranges
Measuring ranges
Number of measuring ranges Max. 4; parameters can be assigned freely
Note
The following metrological data apply to the gas pair H
2
in N
2
. With other gas pairs, these data may di󹪜er from the possible
measuring spans, the time behavior and the measurement behavior as well as the in󹪞uencing variables.
Parameters can be assigned in the measuring
ranges

 Smallest possible measuring span 0.5% H
2
in N
2
 Largest possible span 100% H
2
in N
2
 Smallest possible span with suppressed zero
point
5% (e.g. 95 to 100%) H
2
in N
2
Table 13-30 CALOMAT 7: Gas inlet conditions
Gas inlet conditions
Sample gas pressure 700to1 400hPa (absolute)
Pressure drop between sample gas inlet and outlet <50hPa at 1.5l/min
Sample gas 󹪞ow 30to90l/h (0.5to1.5l/min)
Sample gas temperature and humidity 0 … 70 °C (32 ... 158 °F) with relative humidity < 90%, avoid condensation
in the gas path (moisture content results in measurement errors)
Table 13-31 CALOMAT 7: Temperature of sample chamber and gas path
Temperature of sample chamber and gas path
Gas path 5K above ambient temperature
Standard version 72°C (162°F)
Technical speci󹪝cations
13.3Technical speci󹪝cations of analyzer modules
