Siemens SIPROCESS GA700 Operating Instructions

Table 13-16 OXYMAT 7: Parts in contact with sample gases
Materials of wetted parts OXYMAT 7 OXYMAT 7 high-temperature
1)
Sample chamber Stainless steel:
• Plates: Material No. 1.4571
• Screw-in glands: Material No. 1.4571
Hastelloy:
• Plates: Material No. 2.4602
• Screw-in glands: Material No. 2.4819
Stainless steel:
• Plates: Material No. 1.4571
Hastelloy:
• Plates: Material No. 2.4602
Gas path

With hoses FPM -
With pipes Stainless steel:
• Pipes: Material No. 1.4404
• Gas connections: Material No. 1.4571
Hastelloy:
• Pipes: Material No. 2.4602
• Gas connections: Material No. 2.4602
Stainless steel:
• Gas connections: Material No. 1.4571
Hastelloy:
• Gas connections: Material No. 2.4602
Sealing material FKM (e.g. Viton) or FFKM (Kalrez6375)
1)
The high-temperature version of the analyzer module is not intended for installation in the rack-mounted device.
13.3.2 Technical data ULTRAMAT 7
Table 13-17 ULTRAMAT 7: General technical speci󹪝cations
General ULTRAMAT 7 ULTRAMAT 7 high-temperature
1)
Information on the smallest span See module nameplate
Max. power consumption ≤ 30W ≤ 120W
Weight (only module) Max. 5.2kg Max. 7.2kg
Electrical safety In accordance with DINEN61010-1
Max. EMC error during operation with one
and/or two OXYMAT 7/ ULTRAMAT 7 units
1.0% according to EN 61326-1 (2013)
1)
The high-temperature version of the analyzer module is not intended for installation in the rack-mounted device.
Technical speci󹪝cations
13.3Technical speci󹪝cations of analyzer modules
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 167
