Siemens SIPROCESS GA700 Operating Instructions

Technical speci󹪝cations
13
13.1 Determining the technical speci󹪝cations
The technical speci󹪝cations are obtained based on the speci󹪝cations of DIN EN 61207-1. Unless
speci󹪝ed otherwise, the data listed below relates to the following measurement conditions.
Technical speci󹪝cations OXYMAT 7 ULTRAMAT 7 CALOMAT 7
Ambient temperature 25 °C (77 °F)
Ambient pressure Atmospheric (approx. 1 000hPa)
Sample gas 󹪞ow 0.6 Nl/min; Nl = Standard liter
Sample gas humidity Dew point < -40°C (-40°F)
Site of installation Free of vibration, shock and impact
Reference gas Nitrogen (N
2
) Standard: Nitrogen (N
2
)
Option: freely selectable
1)
-
Reference application - - Hydrogen in nitrogen
(H
2
in N
2
)
2)
1)
For devices with 󹪝lled reference gas side
2)
The technical speci󹪝cations for time and measuring response as well as for the in󹪞uencing variables can sometimes di󹪜er
signi󹪝cantly for other gas mixtures
13.2 Technical speci󹪝cations of the wall housing
Table 13-1 Wall housing: General technical speci󹪝cations
General
Installation position Vertical
Weight Approx. 23kg
Degree of protection IP65 according to EN60529
Table 13-2 Wall housing: Electrical characteristics
Electrical characteristics
Auxiliary power supply 100to240VAC (nominal range of use 85to264V)
50to60Hz (nominal range of use 47to63Hz)
Power consumption Max. 280VA
EMC interference immunity
(electromagnetic compati‐
bility) during operation:
with one or two OXY‐
MAT7 / ULTRAMAT7
units
in accordance with the standard requirements of NA‐
MURNE21(05/2006) and EN61326-1(2013)
with one or two CALO‐
MAT7 units
in accordance with standard requirements of EN61326-1(2013)
Wall-mounted device
Operating Instructions, 07/2023, A5E31930403-AB 161
