Triumph Street Cup User Manual

General Information
30
High Coolant Temperature Warning
Light
With the engine running, if the
engine coolant temperature becomes
dangerously high, the high coolant
temperature warning light will illuminate.
Caution
Stop the engine immediately if the high
coolant temperature warning light
illuminates. Do not restart the engine
until the fault has been rectified.
Severe engine damage will result from
running the engine when the high
coolant temperature warning light is
illuminated.
Immobiliser/Alarm Indicator Light
This Triumph motorcycle is
fitted with an engine immobiliser which
is activated when the ignition switch is
turned to the OFF position.
When the ignition switch is turned to
the OFF position, the immobiliser light
will flash on and off for 24 hours to
show that the engine immobiliser is on.
When the ignition switch is turned to
the ON position the immobiliser and the
indicator light will be off.
If the indicator light remains on it
indicates that the immobiliser has a
malfunction that requires investigation.
Contact an authorised Triumph dealer
as soon as possible to have the fault
checked and rectified.
With Alarm Fitted
The immobiliser/alarm light will only
illuminate when the conditions
described in the genuine Triumph
accessory alarm instructions are met.
Without Alarm Fitted
When the ignition switch is turned to
the OFF position, the immobiliser/alarm
light will flash on and off for 24 hours to
show that the engine immobiliser is on.
When the ignition switch is turned to
the ON position the immobiliser and the
indicator light will be off.
If the indicator light remains on it
indicates that the immobiliser has a
malfunction that requires investigation.
Contact an authorised Triumph dealer
as soon as possible to have the fault
checked and rectified.
ABS (Anti-Lock Brake System)
Warning Light
The ABS warning light
illuminates to show that the ABS
function is not available. Illumination is
normal after engine start up, and until
the motorcycle first reaches a speed
exceeding 6 mph (10 km/h). Unless there
is a fault, it should not illuminate again
until the engine is restarted.
If the warning light becomes illuminated
at any other time while riding it
indicates that the ABS has a
malfunction that requires investigation.

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
