Triumph Street Cup User Manual

General Information
31
Warning
If the ABS is not functioning, the brake
system will continue to function as a
non‑ABS braking system. Do not contin‑
ue to ride for longer than is necessary
with the indicator light illuminated.
Contact an authorised Triumph dealer
as soon as possible to have the fault
checked and rectified. In this situation
braking too hard will cause the wheels
to lock resulting in loss of motorcycle
control and an accident.
Traction Control (TC) Indicator Light
The TC indicator light is used to
indicate that the traction control
system is active and is working to limit
rear wheel slip during periods of hard
acceleration or under wet or slippery
road conditions.
Warning
If the traction control is not functioning,
care must be taken when accelerating
and cornering on wet/slippery road
surfaces to avoid rear wheel spin. Do
not continue to ride for longer than is
necessary with the Engine Management
System Malfunction Indicator Light (MIL)
and traction control warning lights
illuminated. Contact an authorised
Triumph dealer as soon as possible to
have the fault checked.
Hard acceleration and cornering in this
situation may cause the rear wheel to
spin resulting in loss of motorcycle
control and an accident.
TC Indicator Light Operation:
TC Switched On:
• Under normal riding conditions the
indicator light will remain off.
• The indicator light will flash rapidly
when the traction control system is
working to limit rear wheel slip
during periods of hard acceleration
or under wet or slippery road
conditions.
TC Switched Off:
The indicator light will not illuminate.
Instead the TC disabled warning light
will be illuminated (see page 31).
Note:
• Traction control will not function if
there is a malfunction with the ABS
system. The warning lights for the
ABS, traction control and the MIL
will be illuminated.
Traction Control (TC) Disabled
Warning Light
The TC disabled warning light
should not illuminate unless traction
control is switched off or there is a
malfunction.
If the warning light becomes illuminated
at any other time while riding, it
indicates that the traction control has a
malfunction that requires investigation.

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
