Triumph Street Cup User Manual

General Information
64
Passenger Seat Removal
To remove the passenger seat:
cjyn
2
1
1. Passenger seat
2. Fixing
Remove the fixing securing the
passenger seat to the luggage rack
frame.
Lift the seat up from the back and slide
rearwards to remove it from the
motorcycle.
Rider’s Seat Removal
To remove the rider’s seat:
Remove the passenger seat if fitted.
1
1. Seat lock
Insert the ignition key into the seat lock
and turn it anticlockwise while pressing
down on the rear of the seat.
This will release the seat from its lock.
Lift the seat up from the back and slide
rearwards to remove it from the
motorcycle.
Street Scrambler Seat Installation
Warning
To prevent detachment of a seat
during riding, after fitting always grasp
the seat and pull firmly upwards. If the
seat is not correctly secured it will
detach from the lock.
If the seat is not correctly secured it
will detach from the lock.
A loose or detached seat could cause
loss of motorcycle control and an
accident.
Rider’s Seat Installation
To install the rider’s seat:
Engage the seat’s tongue under the fuel
tank.
Note:
• An audible click can be heard when
the seat is correctly engaged in the
lock.
Press firmly down in the centre of the
seat to engage the lock.
Grasp the seat and make sure it is
securely retained.

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
