Triumph Street Cup User Manual

General Information
60
Right Hand Side Panel
The right hand side panel can be
removed to gain access to the rear
brake fluid reservoir.
1
3
4
2
1. Side panel (right hand shown)
2. Upper grommets
3. Lower grommets
4. Side panel attached to lower grommet
Note:
• The exhaust system is shown
removed for clarity.
To remove the right hand side panel:
Grasp the panel firmly at the top and pull
the panel away from the motorcycle until
it is free from the two top retaining
grommets, leaving the grommets in place.
Lift up the panel to detach it from the
lower grommet.
To refit the right hand side panel:
Position the side panel on to the lower
grommet.
Make sure that the slot in the panel is
fully engaged with the lower grommet.
Position the two locating dowels to the
upper grommets, then press firmly to
secure the panel.
Finally, grasp the panel and make sure
that it is fully retained.
Tool Kit and Owner’s
Handbook
Tool Kit
The tool kit consists of an adjustment
tool.
citg
1
1. Adjustment tool
Street Twin, Street Cup, Thruxton,
Thruxton R, Bonneville T120 and
Bonneville T100
The adjustment tool is attached to the
inside of the right hand side panel.
Street Scrambler
The adjustment tool is attached to the
inside of the left hand side panel.
Thruxton R
There are two C‑spanners located under
the seat.

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
