General Information
50
Left Handlebar Switches
cixb
1
2
3
4
5
6
1. SCROLL button
2. Horn button
3. Direction indicator switch
4. MODE button (Thruxton R only)
5. Daytime Running Lights (DRL) switch
(if fitted)
6. High beam button
SCROLL Button
The SCROLL button is used to operate
the following functions of the
instruments:
Odometer functions (see page 37)
Trip reset (see page 37)
Clock reset (see page 38)
Traction control functions
(see page 41).
Horn Button
When the horn button is pushed, with
the ignition switch turned to the ON
position, the horn will sound.
Direction Indicator Switch
When the direction indicator switch is
pushed to the left or right, the
corresponding direction indicators will
flash on and off.
The indicators can be cancelled
manually. To manually turn off the
indicators, press and release the
indicator switch in the central position.
MODE Button (if fitted)
The MODE button allows throttle
response adjustment. Press and release
the MODE button to select one of the
different rider modes available (see
page 39 for more information).
Daytime Running Lights (DRL)
Switch (if fitted)
Note:
Daytime running lights are
manually operated. They are not
automatic.
The daytime running lights or dip beam
can be selected with the Daytime
Running Lights (DRL) switch.
To select daytime running lights, push
the DRL switch forward.
To select dip beam, push the DRL switch
rearwards.
When the daytime running lights are
turned on, the daytime running lights
indicator light will illuminate in the
instrument panel.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Street Cup and is the answer not in the manual?

Triumph Street Cup Specifications

General IconGeneral
Engine Capacity900 cc
Max Torque80 Nm @ 3, 230 rpm
Fuel SystemMultipoint sequential electronic fuel injection
Transmission5-speed
FrameTubular steel cradle
Rear SuspensionKYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front BrakesSingle 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight200 kg
Bore x Stroke84.6 x 80 mm
Compression Ratio10.55:1
Final DriveChain
ClutchWet, multi-plate assist clutch
Front Tyre100/90-18
Engine TypeLiquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power55 PS (54 hp) @ 5, 900 rpm
ExhaustBrushed stainless steel twin silencers
Front Suspension41mm forks
Rear BrakesSingle 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height780 mm
Fuel Tank Capacity12 L
SwingarmTwin-sided, tubular steel
Front Wheel18 x 2.75 in
Rear Wheel17 x 4.25 in
Instrument Display and FunctionsAnalogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)740 mm
Rake25.5°
