Triumph Street Cup User Manual

General Information
51
High Beam Button
When the high beam button is pressed
the high beam will be switched on. Each
press of the button will swap between
dip and high beam.
Note:
• If daytime running lights are fitted
to the motorcycle, the high beam
button has additional functionality.
If the DRL switch is in the daytime
running lights position, then press and
hold the high beam button to turn the
high beam on. It will remain on as long
as the button is held in and will turn off
as soon as the button is released.
Note:
• A lighting on/off switch is not fitted
to this model. The position light,
rear light and licence plate light all
function automatically when the
ignition is turned to the ON position.
• The headlight will function when
the ignition switch is turned to the
ON position. The headlight will go
off while pressing the starter
button until the engine starts.
Heated Grips (if fitted)
The heated grips work when the ignition
is switched on. However, it is
recommended that they are only used
when the engine is running to avoid
draining the battery.
There are two heat levels; low or high.
c
j
p
j
1
1. Heated grips button
The heated grips button is located on
the left hand grip.
Press the heated grip button to show
the current status of the heated grips
in the display screen. This is shown for
three seconds.
Press the heated grip button whilst the
status is showing to select one of the
three different heat levels; OFF, Lo (low)
or HI (high).
For maximum benefit in cold conditions,
use the heated grips on the HI level
initially and when the grips have
warmed up, change to Lo.
To switch off the heated grips, press
and release the button until OFF is
shown in the display screen. The heated
grips are also switched off when the
ignition is switched off.

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
