Triumph Street Cup User Manual

General Information
33
Low Fuel Indicator Light
The low fuel indicator light will
illuminate when there are approximately
3.0 litres of fuel remaining in the tank.
Tyre Pressure Warning Light
Note:
• Tyre Pressure Monitoring System
(TPMS) is an accessory option only
available on models fitted with cast
alloy wheels.
The tyre pressure warning
light works in conjunction with the Tyre
Pressure Monitoring System (TPMS) (see
page 44).
The warning light will only illuminate
when the front or rear tyre pressure is
below the recommended pressure. It will
not illuminate if the tyre is over inflated.
When the warning light is illuminated,
the TPMS symbol indicating which is the
deflated tyre and its pressure will
automatically be visible in the display
screen.
10
20
1
10
1
20
1
20
0
0
20
40
60
1
80
200
1
2
3
4
1. Tyre pressure warning light
2. TPMS symbol
3. Tyre pressure
4. Front and rear tyre indicators
The tyre pressure at which the warning
light illuminates is temperature
compensated to 20°C but the numeric
pressure display associated with it is
not. Even if the numeric display seems
at or close to the standard tyre
pressure when the warning light is on, a
low tyre pressure is indicated and a
puncture is the most likely cause.
Warning
Stop the motorcycle if the tyre
pressure warning light illuminates.
Do not ride the motorcycle until the
tyres have been checked and the tyre
pressures are at their recommended
pressure when cold.

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
