Triumph Street Cup User Manual

General Information
44
Tyre Pressure Monitoring
System (TPMS) (if fitted)
Warning
The daily check of tyre pressures must
not be excluded because of the fitment
of the TPMS. Check the tyre pressure
when the tyres are cold using an
accurate tyre pressure gauge (see
page 121).
Use of the TPMS system to set
inflation pressures may lead to
incorrect tyre pressures leading to loss
of motorcycle control and an accident.
Note:
• Tyre Pressure Monitoring System
(TPMS) is an accessory option only
available on models fitted with cast
alloy wheels.
Function
Tyre pressure sensors are fitted to the
front and rear wheels. These sensors
measure the air pressure inside the tyre
and transmit pressure data to the
instruments. These sensors will not
transmit the data until the motorcycle is
travelling at a speed greater than
12 mph (20 km). Two dashes will be
visible in the display screen until the
tyre pressure signal is received.
The Tyre Pressure Monitoring System
(TPMS) is an accessory fitted item and
must be fitted by your authorised
Triumph dealer.
The TPMS display screen on the
instruments will only be activated when
the system has been fitted.
An adhesive label will be fitted to the
wheel rim to indicate the position of the
tyre pressure sensor which is near the
valve.
Tyre Pressure Sensor Serial Number
The serial number for the tyre pressure
sensor is printed on a label attached to
the sensor. This number may be
required by your authorised Triumph
dealer for service or diagnostics.
When the tyre pressure monitoring
system is being fitted to the motorcycle,
make sure that your authorised Triumph
dealer records the serial numbers of the
front and rear tyre pressure sensors in
the spaces provided below.
Front Tyre Pressure Sensor
Rear Tyre Pressure Sensor

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
