Triumph Street Cup User Manual

Maintenance And Adjustment
99
Drive Chain
cbnz
Warning
A loose or worn chain, or a chain that
breaks or jumps off the sprockets
could catch on the engine sprocket or
lock the rear wheel.
A chain that snags on the engine
sprocket will injure the rider and lead
to loss of motorcycle control and an
accident.
Similarly, locking the rear wheel will
lead to loss of motorcycle control and
an accident.
For safety and to prevent excessive
wear the drive chain must be checked,
adjusted and lubricated in accordance
with scheduled maintenance
requirements. Checking, adjustment and
lubrication must be carried out more
frequently for extreme conditions such
as salty or heavily gritted roads.
If the chain is badly worn or incorrectly
adjusted (either too loose or too tight)
the chain could jump off the sprockets
or break. Therefore, always replace worn
or damaged chains using genuine
Triumph parts supplied by an authorised
Triumph dealer.
Drive Chain Lubrication
Lubrication is necessary every 200 miles
(300 km) and also after riding in wet
weather, on wet roads, or any time that
the chain appears dry.
Use the special chain lubricant as
recommended in the Specifications
section.
Apply lubricant to the sides of the
rollers then allow the motorcycle to
stand unused for at least eight hours
(overnight is ideal). This will allow the oil
to penetrate to the chain O‑rings etc.
Before riding, wipe off any excess oil.
If the chain is especially dirty, clean first
and then apply oil as mentioned above.
Caution
Do not use a pressure washer to clean
the chain as this may cause damage to
the chain components.

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
