General Information
48
In addition to operating the ignition
switch/steering lock, the ignition key is
required to operate the seat lock and
fuel tank cap.
When the motorcycle is delivered from
the factory, two ignition keys are
supplied together with a small tag
bearing the key number. Make a note of
the key number and store the spare key
and key number tag in a safe place
away from the motorcycle.
A transponder is fitted within the
ignition keys to turn off the engine
immobiliser. To make sure the
immobiliser functions correctly, always
have only one of the ignition keys near
the ignition switch. Having two ignition
keys near the switch may interrupt the
signal between the transponder and the
engine immobiliser. In this situation the
engine immobiliser will remain active
until one of the ignition keys is removed.
Always get replacement keys from your
authorised Triumph dealer. Replacement
keys must be 'paired' with the
motorcycle’s immobiliser by your
authorised Triumph dealer.
Right Handlebar Switches
Street Twin, Street Cup,
Street Scrambler and Thruxton R
cite
4
1
5
2
3
1. Engine start/stop switch
2. STOP position
3. RUN position
4. START position
5. Hazard warning light switch
Thruxton, Bonneville T100 and
Bonneville T120
cjai
1
5
4
3
2
6
1. Engine start/stop switch
2. STOP position
3. RUN position
4. START position
5. MODE button (Thruxton and
Bonneville T120 only)
6. Hazard warning light switch

Triumph Street Cup Specifications

General

Engine Capacity	900 cc
Max Torque	80 Nm @ 3, 230 rpm
Fuel System	Multipoint sequential electronic fuel injection
Transmission	5-speed
Frame	Tubular steel cradle
Rear Suspension	KYB twin shocks with adjustable preload, 120 mm rear wheel travel
Front Brakes	Single 310 mm disc, Nissin 2-piston floating caliper, ABS
Dry Weight	200 kg
Bore x Stroke	84.6 x 80 mm
Compression Ratio	10.55:1
Final Drive	Chain
Clutch	Wet, multi-plate assist clutch
Front Tyre	100/90-18
Engine Type	Liquid-cooled, 8 valve, SOHC, 270° crank angle parallel twin
Max Power	55 PS (54 hp) @ 5, 900 rpm
Exhaust	Brushed stainless steel twin silencers
Front Suspension	41mm forks
Rear Brakes	Single 255 mm disc, Nissin 2-piston floating caliper, ABS
Seat Height	780 mm
Fuel Tank Capacity	12 L
Swingarm	Twin-sided, tubular steel
Front Wheel	18 x 2.75 in
Rear Wheel	17 x 4.25 in
Instrument Display and Functions	Analogue speedometer, fuel gauge and gear position indicator
Width (Handlebars)	740 mm
Rake	25.5°
