Xerox 4112 System Administration Guide

Using the Scan Service
Xerox 4112/4127 Copier/Printer 5-9
System Administration Guide
Enabling the ports and setting the IP addresses
In order to use FTP service on the machine, enable the port and set the IP address.The
procedure for setting the machine is as follows.
Note
The configuration can also be performed using CentreWare Internet Services. Refer to “Using
CentreWare Internet Services”
1. Enter the System Administrator Mode (Chapter 1 Entering the System Administrator mode
on page 1-10.)
2. Enable the SNMP port.
a. Select System Settings.
b. Select Connectivity & Network Setup.
c. Select Port Settings.
d. Select SNMP and then select Change Settings.
e. Select Port Status and select Change Settings.
f. Select Enable and then select Save.
g. Select Close
3. Enable the FTP client port and Internet service (HTTP) port as above.
4. Select Close.
5. If necessary, set the IP Address (Chapter 1 Setting the IP address on page 1-11).
6. Exit the System Administrator Mode (Chapter 1 Exiting the System Administrator mode on
page 1-11).
7. After the machine is restarted, print out the Printer Settings List to confirm that the ports
are enabled and TCP/IP is configured.
Configuring the SNMP port
Configure the transport protocol for the SNMP port using CentreWare Internet Services.
1. Start a web browser.
2. Enter the machine’s IP address or the Internet address to the address entry column on the
browser, and press the Enter key.
• Example of the IP address entry:
• http://192.168.1.1/
• Example of the Internet address entry:
• http://xxx.yyyy.zz.vvv/
Note
When specifying a port number, add “:” and a port number to the end of the Internet
address.
3. Click the Properties tab.
4. Click Port Status from the Properties area.
5. Select the UDP checkbox to the right of SNMP (Port Status feature).
6. Reflect the values as the setting values of the machine.
a. Click the Apply button.
b. Enter the System Administrator UserID and password into User Name and Password,
and then click OK.
