10-4 Phaser 6250 Color Laser Printer Service Manual
140 3 Connects: Engine Control Board, CRUM Harness Assembly, Toner Full
Sensor Harness Assembly, EEPROM Circuit Board.
141 3 EEPROM Harness Assembly Chute Assembly, In
(Toner Full Sensor)
142 2 Chute Assembly In
(Toner Full Sensor)
EEPROM Harness Assembly
144 3 EEPROM Circuit Board (Yellow
goes to top connector)
Engine Control Board
145 3 EEPROM Circuit Board (Grey
goes to bottom connector)
Fuser Harness
151 2 Laser Unit Engine Control Board
161 2 LVPS Assembly Power Cord
162 2 LVPS Assembly Fuser Assembly
163 2 LVPS Assembly Motor Driver Board
164 2 LVPS Assembly Engine Control Board
165 2 LVPS Assembly Motor Driver Board
166 2 LVPS Assembly Rear Fan
167 2 NC NC
168 2 NC Engine Control Board
181 3 Chute Assembly, Registration
(Registration Sensor)
Engine Control Board
210 2 Lower Feeder Harness Assy HCF-Plug
FPC* 1 Front Panel OPEPANE Harness Assembly
221 3 OPEPANE Harness Assembly Front Panel
231 4 Temp/Humidity Sensor Temp/Humidity Harness Assembly
232 2 Fuser Assembly FRONT 1A Harness Assembly
311 3 Engine Control Board LVPS Assembly
321 3 OHP Sensor Engine Control Board
341 1 CRUM Reader Board CRUM Reader Harness
*FPC = Front Panel Connector
Plug/Jack Locator Table (Continued)
P/J
No. Map Connected to... Other end connected to...
