Yamaha YP125R Service Manual

FRONT BRAKE
4-17
EAS22210
FRONT BRAKE
Removing the front brake pads
Order Job/Parts to remove Q’ty Remarks
1 Front brake caliper bolt 2
2 Speed sensor lead guide 1
3 Front brake caliper 1
4 Brake pad pin cap 1
5 Brake pad pin 1
6 Front brake pad 2
7 Brake pad spring 1
8 Brake pad support 1
For installation, reverse the removal proce-
dure.
3
7
6
6
8
1
2
1
5
4
40 Nm (4.0 m
•
kgf, 29 ft
•
Ibf)
T
.R.
18 Nm (1.8 m
•
kgf, 13 ft
•
Ibf)
T
.R.
3 Nm (0.3 m
•
kgf, 2.2 ft
•
Ibf)
T
.R.
6 Nm (0.6 m
•
kgf, 4.3 ft
•
Ibf)
T
.R.

Yamaha YP125R Specifications

General

Engine Type	Liquid-cooled, 4-stroke, SOHC, 4-valve
Bore x Stroke	52.4 mm x 57.9 mm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	V-Belt Automatic
Front Suspension	Telescopic fork
Rear Suspension	Unit Swing
Front Brake	Hydraulic single disc, Ø267 mm
Starter System	Electric
Rear Tyre	140/70-14M/C 62P (Tubeless)
