Zebra L10 User Manual

Data Capture
109
Using the Barcode Scanner (XPAD Only)
The optional XPAD L10 scanner is a factory-installed device consisting of a barcode optical image reader and
hardware decoder. The SE4710 scanner is built in to the handle of the XPAD L10 tablet.
Figure 78 Barcode Scanner
1. On the tablet, open the application software that is going to receive the barcode data and put the active cursor
in the appropriate field of that software.
2. Aim the scanner lens at the barcode.
3. Press and hold the Barcode Scanning button on top of the handle. Make sure that the red scan beam covers
the entire barcode.
Figure 79 Barcode Scanning Button
If the scan is successful, there is a confirmation beep and the data appears in the application.
Barcode
Scanner
Barcode
Scanner
Barcode
Scanner Button
