Zebra L10 User Manual

Data Capture
113
Figure 84 Aiming Pattern
Figure 85 Picklist Mode with Multiple Barcodes in Aiming Pattern
The captured data appears in the text field.
Barcode Capture with Zebra Scanner
To capture barcode data:
1. Ensure that an application is open on the device and a text field is in focus (text cursor in text field).
2. Point the scanner at a barcode.
Figure 86 Barcode Scanning (DS3678-SR shown)
3. Press and hold the trigger.
Ensure the barcode is within the area formed by the aiming pattern. The aiming dot is used for increased
visibility in bright lighting conditions. The aiming dot is used for increased visibility in bright lighting conditions.
