Specifications
163
Drop Specification MIL STD 810G at 25°C; This specification is for dropping the tablet up to 1.83 m (6
feet) to plywood and up to 1.2 m (4 feet) to concrete.
Electrostatic Discharge
(ESD)
± 8 kV direct discharge
± 15 kV air discharge
Hazardous Location
C1D2 and ATEX rating for use in hazardous locations
Display
Corning Gorilla Glass 3 for increased display damage resistance
Wireless Communications
WWAN
Global LTE with WCDMA fallback
North America: AT&T LTE with AT&T WCDMA 3G fallback; Verizon LTE
WLAN
WLAN: 802.11 a/b/g/n/d/h/i/k/r/ac, IPv4, IPv6; MU-MIMO, 2x2
• 2.4 GHz: 802.11b/g/n - up to 144 Mb per second;
Chan 1 - 13 (2412 - 2472 MHz),
• 5 GHz: 802.11a/n/ac - up to 866.7 Mb per second;
Chan 36 - 165 (5180 - 5825 MHz)
• Channel Bandwidth: 20, 40, 80 MHz
• Actual operating channels/frequencies depend on regulatory rules and
certification agency.
• WEP (40 or 104 bit); WPA/WPA2 Personal (TKIP and AES);
• WPA/WPA2 Enterprise (TKIP and AES) - EAP-TTLS (PAP, MSCHAP,
MSCHAPv2), EAP-TLS, PEAPv0-MSCHAPv2, PEAPv1-EAP-GTC, EAP
LEAP.
Bluetooth
Bluetooth v5.0 and BLE (Bluetooth low energy)
Near Field
Communication (NFC)
NFC is a subset of RFID with a shorter communication range for better security for
data. NFC lets you make payments share data.
P2P: ISO 18092x.
• Reader/Writer: ISO 14443 – A-B, MIFARE, FeliCa®, ISO 15693, NFC Forum
Tag Types 1 to 4
• Card emulation: ISO 14443 – A-B-B’, MIFARE, FeliCa RF
• Distance up to 3 cm
Global Navigation
Satellite Systems
(GNSS)
GPS, Glonass, Galileo, and Beidou
Sensors
Gyro
Maintains orientation based on principles of conservation of angular momentum
Motion Sensor Three-axis accelerometer that enables motion-sensing applications for dynamic
screen orientation and power management
Table 26 Technical Specifications (Continued)
Item Description
