3-20
Confidential
10 Lower cover (left side)
Cable guide
Paper feed motor harness
Cable guides
PF encoder harness
Cable guides
Cable ties
Ferrite cores
Cable tie
<Except for US/CAN>
Ferrite core
Cable guides
Paper tray 2 detection
sensor harness
Paper tray 2 detection
sensor harness
The knot of the
Cable tie should
face downward.
The Cable tie
should be
wrapped
outside the
Harness and
the Ferrite
core.
