Brother MFC-J2320 Service Manual

1-2
Confidential
*1
Only for Hong Kong/Taiwan/Korea
*2
Photo paper is not available.
*3
A3/LGR/LGL Glossy aren't available.
1.3 Paper Handling
1
A3/LGR/LGL/Folio are 5 sheets.
1.4 LCD Panel
Media
Weights
Standard Tray 64-220 g/m
2
(17-58 lb.)
Lower Tray
N/A
64-120 g/m
2
(17-32 lb.)
N/A
64-120 g/m
2
(17-32 lb.)
Manual Feed Slot 64-220 g/m
2
(17-58 lb.)
MP Tray
N/A
64-220 g/m
2
(17-58 lb.)
N/A 64-220 g/m
2
(17-58 lb.)
Duplex Print 64-120 g/m
2
(17-32 lb.)
ADF 64-90 g/m
2
(17-24 lb.)
Media
Types
Standard Tray Plain, Inkjet, Glossy
*3
(cast/resin)
Lower Tray N/A Plain N/A Plain
Manual Feed Slot Plain, Inkjet, Glossy(cast/resin)
MP Tray
N/A
Plain, Inkjet,
Glossy(cast/resin)
N/A Plain, Inkjet, Glossy(cast/resin)
Duplex Print Plain
ADF Plain
Model MFC-J2320 MFC-J2720 MFC-J5320DW
MFC-J5520DW/
J5620DW/
J5625DW
MFC-J5720DW/
J5920DW
Paper Input
(sheets)
Standard Tray 250 (80 g/m
2
)
Lower Tray N/A 250 (80 g/m
2
) N/A 250 (80 g/m
2
)
Manual Feed Slot 1
MP Tray
N/A 80
1
(80 g/m
2
) N/A 80
1
(80 g/m
2
)
ADF 35 (80 g/m
2
) 50 (80 g/m
2
) 35 (80 g/m
2
) 50 (80 g/m
2
)
Output Paper Capacity
(sheets)
50 (80 g/m
2
)
Model MFC-J2320 MFC-J2720 MFC-J5320DW
MFC-J5520DW/
J5620DW/
J5625DW
MFC-J5720DW/
J5920DW
LCD
Type & Size 2.7 inch TFT 3.7 inch TFT 2.7 inch TFT 3.7 inch TFT
Touch-Panel Yes
Model MFC-J2320 MFC-J2720 MFC-J5320DW
MFC-J5520DW/
J5620DW/
J5625DW
MFC-J5720DW/
J5920DW

Brother MFC-J2320 Specifications

General

Brand	Brother
Model	MFC-J2320
Category	All in One Printer
Language	English
