2.5 Components
Fig. 2-6
ADF unit
Document scanner unit
Upper cover
Main PCB ASSY
Wireless LAN PCB ASSY
Modem PCB ASSY
Main PCB frame
Head/carriage unit
Maintenance unit
Ink refill ASSY
Ink cartridge cover
sensor ASSY
Control panel ASSY
(Including the NFC PCB)
Inner media
module cover
Media
module cover
Paper tray ASSY 2
Lower tray
Power supply PCB ASSY
Lower power supply
frame
PF encoder
sensor harness
PF encoder
sensor PCB
ASSY
Flushing
box
Jam clear cover
Registration
sensor PCB ASSY
Engine
related
parts
Lower cover
Switchback
frame ASSY
Ink absorber box
Sensor relay PCB ASSY
Harness cover
Scanner cover
support
Scanner cover damper
MP tray ASSY
Frame
base
Paper tray ASSY 1
Front cover
Ink cartridge
cover
