5-32
Confidential
1.3.16 Fine Adjustment of Scanning Position (Maintenance mode 54)
< Function >
This function adjusts the scanning start and end positions.
< Operating Procedure >
(1) Press the 5 and 4 keys in this order in the initial stage of the maintenance mode.
Simplex scanning models: The "SCAN ADJ SELECT" appears on the LCD. Go to
step (3).
Duplex scanning models: The "0: FRONT 1: BACK" appears on the LCD.
(2) To adjust the first side scanning position, press the 0 key. The "SCAN START
ADJ." appears on the LCD.
To adjust the second side scanning position, press the 1 key. The "SCAN START
ADJ." appears on the LCD.
(3) To adjust the right and left edges, press the 0 key. The "RL EGDE **" appears on
the LCD.
To adjust the top edge, press the 1 key. The "TOP EGDE **" appears on the LCD.
To adjust the bottom edge, press the 2 key. The "BOTM EGDE **" appears on the
LCD.
(4) Enter the correction value (in units of 0.1 mm) multiplied by 10.
To increase the value by 10 (1.0 mm), press the key; to decrease it, press the
key. To increase the value by 1 (0.1 mm), press the key; to decrease it, press the
key.
Note: • Pressing the CLR key resets the correction value to 0.
•Pressing the X key returns the machine to the initial stage of the
maintenance mode without making changes of the correction value.
To Next Page
