3-56
Confidential
9.20 Media Module Cover
(1) Lift up the Control panel ASSY to the front.
(2) Open the Media module cover, release Bosses on either side, and remove the
cover to the front.
Fig. 3-48
Control panel
ASSY
Media module cover
1
2
