Brother MFC-J2320 Service Manual

Confidential
2-25
Ink cartridge side IC chip relation defective
-Identification no match/judge as incompatible cartridge/detecting setting wrong color
The Ink cartridge which does not contain required ink volume for the initial installation
has been set at the initial installation.
User Check
- Check if incompatible ink cartridge is loaded.
- Reload the ink cartridge.
- Replace the ink cartridge.
- Set ink cartridge at position for correct color.
- Set the starter ink cartridge.
Cannot communicate with ink cartridge IC chip (ink cartridge side.)
User Check
- Check if incompatible ink cartridge is loaded.
- Reload the ink cartridge.
- Replace the ink cartridge.

Error Code 24
Cannot Detect / Wrong Color Ink
LCD
Install Starter Ink
LCD
Step Cause Solution
1 Main PCB defective Replace the main PCB ASSY.

Error Code 25
Cannot Detect
LCD
Step Cause Solution
1 Ink sensor flat cable
connection failure
Reconnect the ink sensor flat cable.
2 Ink cartridge IC chip PCB
defective
Replace the ink refill ASSY.
3 Main PCB defective Replace the main PCB ASSY.
