Brother MFC-J2320 Service Manual

1-1
Confidential
CHAPTER 1 SPECIFICATIONS
1GENERAL
1.1 General
1.2 Media Specification
Model All models
Print Head BH15 BK/C/M/Y: 420/420/420/420 nozzles
Minimum Droplet Size
BK: 3 pl
CMY: 1.5 pl
Scanning Method CIS
CPU Speed 288 MHz
Backup Clock Yes (Up to 1 hour)
Model MFC-J2320 MFC-J2720 MFC-J5320DW
MFC-J5520DW/
J5620DW/
J5625DW
MFC-J5720DW/
J5920DW
Media
Sizes
Standard Tray
<Landscape>A4, LTR, EXE,B5
*1
<Portrait>A3
*2
, LGR
*2
, LGL
*2
, B4
*1
, A5, A6, Photo(102 x 152 mm/4 x 6"),
Indexcard(127 x 203 mm/5 x 8"), Photo-L(89x127 mm/3.5 x 5"),
Photo-2L(127x178 mm/5 x 7"), Com-10, DL Envelope, Monarch, C5
Lower Tray
N/A
<Landscape>
A4, LTR
<Portrait>
A3, LGR, B4
*1
,
LGL
N/A
<Landscape>
A4, LTR
<Portrait>
A3, LGR, B4
*1
,
LGL
Manual Feed Slot
<Landscape>A4, LTR, EXE,B5
*1
<Portrait>A3, B4
*1
, LGR, LGL, Folio, A5, A6, Photo(102 x1 52 mm/4 x 6"),
Indexcard(127 x 203 mm/5 x 8"), Photo-L(89 x 127 mm/3.5 x 5"),
Photo-2L(127 x 178 mm/5 x 7"), C5, Com-10, DL Envelope, Monarch
MP Tray
N/A
<Landscape>A4,
LTR, EXE, B5
*1
<Portrait>A3, LGR,
LGL, Folio, A5, A6,
Photo(102x152 mm
/4x6"),
Indexcard(127x203
mm/5x8"), Photo-
L(89x127 mm/
3.5x5"), Photo-
2L(127x178 mm/
5x7"), Com-10, DL
Envelope, Monarch,
C5
N/A
<Landscape>A4, LTR, EXE, B5
*1
<Portrait>A3, LGR, LGL, Folio, A5, A6,
Photo(102x152 mm/4x6"),
Indexcard(127x203 mm/5x8"), Photo-
L(89x127 mm/3.5x5"), Photo-
2L(127x178 mm/5x7"), Com-10, DL
Envelope, Monarch, C5
Duplex Print <PC Print>A4/LTR/EXE/A5/B5
*1
<Copy>A4/LTR/EXE
*1
/A5
ADF (width/length) 148/148 mm to 215.9/355.6 mm (5.8/5.8" to 8.5/14.0")
Scanner Glass
(width/length)
up to 215.9/297 mm (up to 8.5/11.7")
