3-70
Confidential
(3) Remove the Head joint rubber.
Note: Put the Head joint rubber on a clean vinyl sheet and take care not to
contaminate it. Do not touch the Inclination adjuster ring.
Fig. 3-69
Head joint rubber
Head/carriage unit
Inclination
adjuster ring
